Keithley 2614B Reference Manual

Section
2: General operation Series 2600B System SourceMeter® Instrument
Reference Manual
2-18 2600BS-901-01 Rev. B / May 2013
The following table contains descriptions of the main menu options and cross-references to related
information. To access a menu option, press the MENU key, turn the navigation wheel to move the
cursor to select an item, and press the navigation wheel .
Menu selection Description For more information, see:
SCRIPT
Saves and recalls users scripts
Manage scripts (on page 6-3)
- LOAD
Loads scripts into nonvolatile memory
- SAVE
Saves scripts
SETUP
Saves and recalls user and factory setup options
Saved setups (on page 2-46)
- SAVE Saves user setup options
- RECALL
Recalls user setup options
- POWERON
Sets the configuration used during startup
GPIB
Configures the GPIB interface options
Remote communication interfaces (on
page 2-89)
- ADDRESS
Configures the address for the GPIB interface
- ENABLE
Enables and disables the GPIB interface
LAN
Configures the local area network (LAN)
LAN concepts and settings (on page C-1)
- STATUS
Displays LAN connection status
- CONFIG
Configures the LAN IP address and gateway
- APPLY_SETTINGS
Applies changes made using the CONFIG menu
- RESET Restores the default settings
- ENABLE
Enables and disables the LAN interface
RS232
Controls the options for the RS-232 interface
Remote communication interfaces (on
page 2-89)
- BAUD
Sets the baud rate
- BITS
Configures the number of bits
- PARITY Sets the parity
- FLOW-CTRL
Configures the flow control
- ENABLE
Enables and disables the RS-232 interface
TSPLINK
1
Configure the instrument in a TSP-Link
®
network
TSP-Link system expansion interface (on
page 6-47)
- NODE
Selects the instrument node identifier
- RESET
Resets the TSP-Link network
UPGRADE
Upgrades the firmware from a USB flash drive
Upgrading the firmware (on page A-4)
DISPLAY
Accesses display functions
Front panel tests (on page A-2)
- TEST
Runs the display test
See Numeric entry method in Setting a
value (on page 2-21)
- NUMPAD
Enables and disables the numeric keypad
DIGOUT
2
Controls digital outputs
Digital I/O (on page 3-83)
- DIG-IO-OUTPUT
Selects the digital I/O values
- WRITE-PROTECT
Write-protects specific digital I/O lines
BEEPER
Controls the key beeps General operation (on page 2-1)
- ENABLE
Enables the key beeps
- DISABLE
Disables the key beeps
LINE-FREQ
Configures the line frequency General operation (on page 2-1)
- 50Hz
Set the line frequency to 50 Hz
- 60Hz
Set the line frequency to 60 Hz
- AUTO
Enables automatic line frequency detection during
start up
SYSTEM-INFO
Displays the system information
General operation (on page 2-1)
- FIRMWARE
Displays the version of firmware installed
- SERIAL# Displays the serial number of the unit
- CAL
Displays the last calibration date
- MEMORY-USAGE
Displays memory usage in percentage
RESET-PASSWORD
Resets the system password Password management (on page 6-34
)
1. TSPLINK is not available on the Models 2604B, 2614B, and 2634B.
2. DIGOUT is not available on the Models 2604B, 2614B, and 2634B.
