Section
7: TSP command reference Series 2600B System SourceMeter® Instrument
Reference Manual
7-274 2600BS-901-01 Rev. B / May 2013
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents (on
page E-1) and Enable and transition registers (on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
B0
Not used
Not applicable.
B1
status.operation.instrument.SMUA
Set bit indicates one or more
enabled bits for the operation
status SMU A summary register is
set.
Bit B1 decimal value: 2
B2
status.operation.instrument.SMUB
This bit is only available on Models
2602B/2604B/2612B/2614B/2634B
/2636B. Set bit indicates one or
more enabled bits for the operation
status SMU B summary register is
set.
Bit B2 decimal value: 4
B3-B9
Not used
Not applicable.
B10
status.operation.instrument.TRIGGER_BLENDER
status.operation.instrument.TRGBLND
Set bit indicates one or more
enabled bits for the operation
status trigger blender summary
register is set.
Bit B10 decimal value: 1,024.
B11
status.operation.instrument.TRIGGER_TIMER
status.operation.instrument.TRGTMR
Set bit indicates one or more
enabled bits for the operation
status trigger timer summary
register is set.
Bit B11 decimal value: 2,048
B12
status.operation.instrument.DIGITAL_IO
status.operation.instrument.DIGIO
This bit is only available on Models
2601B/2602B/2611B/
2612B/2635B/2636B. Set bit
indicates one or more enabled bits
for the operation status digital I/O
summary register is set.
Bit B12 decimal value: 4,096
B13
status.operation.instrument.TSPLINK
This bit is only available on Models
2601B/2602B/2611B/
2612B/2635B/2636B. Set bit
indicates one or more enabled bits
for the operation status TSP-Link
summary register is set.
Bit B13 decimal value: 8,192
B14
status.operation.instrument.LAN
Set bit indicates one or more
enabled bits for the operation
status LAN summary register is set.
Bit B14 decimal value: 16,384
B15
Not used
Not applicable.
As an example, to set bit B1 of the operation status instrument summary enable register, set
status.operation.instrument.enable = status.operation.instrument.SMUA.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
To set more than one bit of the register, set operationRegister to the sum of their decimal weights. For
example, to set bits B1 and B10, set operationRegister to 1,026 (which is the sum of 2 + 1,024).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
)
(2
6
)
(2
5
)
(2
4
)
(2
3
)
(2
2
)
(2
1
)
(2
0
)
