8: Troubleshooting guide Series 2600B System SourceMeter® Instrument
8-6 2600BS-901-01 Rev. B / May 2013
Error summary
Error number Error level Error Message
Operation not permitted while cal is locked
Cal data not saved - save or restore before lock
Cannot save cal data - unlock before save
Cannot restore cal data - unlock before restore
Save to cal set disallowed
Cannot change cal date - unlock before operation
5017 RECOVERABLE Cannot change cal constants - unlock before operation
Cal version inconsistency
Cannot unlock - invalid password
Cannot restore default calset. Using previous calset
Cannot restore previous calset. Using factory calset
Cannot restore factory calset. Using nominal calset
Cannot restore nominal calset. Using firmware defaults
5025 RECOVERABLE Cannot set filter.count > 1 when measure.count > 1
Unlock cal data with factory password
Cannot perform requested operation while source autorange is
enabled
Cannot save without changing cal adjustment date
5032 RECOVERABLE Cannot change this setting unless buffer is cleared
Reading buffer not found within device
Index exceeds maximum reading
5040 RECOVERABLE
Cannot use same reading buffer for multiple overlapped
Output Enable not asserted
Cannot perform requested action while an overlapped operation is in
progress
Cannot perform requested operation while voltage measure
autorange is enabled
Cannot perform requested operation while current measure
autorange is enabled
Cannot perform requested operation while filter is enabled
5046 SERIOUS SMU too hot
Minimum timestamp resolution is 1us
Contact check not valid with HIGH-Z OUTPUT off
Contact check not valid while an active current source
I limit too low for contact check
Model number/SMU hardware mismatch. Disconnect DUT and cycle
power
Interlock engaged; system stabilizing
Unstable output detected - Measurements may not be valid
5055 RECOVERABLE
Cannot change adjustment date - change cal constants before
5059 RECOVERABLE trigger.source.action enabled without configuration
trigger.measure.action enabled without configuration
Operation not permitted while OUTPUT is off
5063 RECOVERABLE Cannot perform requested operation while measure autozero is on
Cannot use reading buffer that collects source values
I range too low for contact check
source.offlimiti too low for contact check
Autorange locked for HighC mode
