Keithley DMM7510 Calibration Manual

Section
2: Performance verification Model DMM7510 7½ Digit Graphical Sampling Multimeter
Calibration Manual
2-24 DMM7510-905-01 Rev. A / April 2015
Verify the analog trigger voltage 100 mV range
Description Verification point Lower limit Upper limit
Measure or Digitize DC-coupled
50 % scale rising
0.05
0.0490
0.0510
Measure or Digitize DC-coupled
50 % scale falling
-0.05 -0.0510 -0.0490
Digitize AC-coupled
50 % scale rising
0.05
0.0485
0.0515
Digitize AC-coupled
50 % scale falling
-0.05 -0.0515 -0.0485
Verify the analog trigger voltage 1 V range
Description Verification point Lower limit Upper limit
Measure or Digitize DC-coupled
50 % scale rising
0.5
0.4900
0.5100
Measure or Digitize DC-coupled
50 % scale falling
-0.5
-0.5100
-0.4900
Digitize AC-coupled
50 % scale rising
0.5
0.4850
0.5150
Digitize AC-coupled
50 % scale falling
-0.5 -0.5150 -0.4850
Verify the analog trigger voltage 10 V range
Description Verification point Lower limit Upper limit
Measure or Digitize DC-coupled
50 % scale rising
5
4.900
5.100
Measure or Digitize DC-coupled
50 % scale falling
-5
-5.100
-4.900
Digitize AC-coupled
50 % scale rising
5
4.850
5.150
Digitize AC-coupled
50 % scale falling
-5 -5.150 -4.850
Verify the analog trigger voltage 100 V range
Description Verification point Lower limit Upper limit
Measure or Digitize DC-coupled
50 % scale rising
50 49.00 51.00
Measure or Digitize DC-coupled
50 % scale falling
-50
-51.00
-49.00
Digitize AC-coupled
50 % scale rising
50
48.50
51.50
Digitize AC-coupled
50 % scale falling
-50
-51.50
-48.50
