Keithley DMM7510 Calibration Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Calibration Manual Section 2:
Performance verification
DMM7510-905-01 Rev. A / April 2015 2-51
Verify DC current 1 A range
Description Calibrator
setpoint (A)
Lower limit Upper limit
UUT Zero STANDBY -5.0000000E-05 5.0000000E-05
Full scale (+)
0
9.9955000E-01
1.0004500E+00
Half scale (+)
1
4.9975000E-01
5.0025000E-01
Half scale (-)
0.5
-5.0025000E-01
-4.9975000E-01
Full scale (-)
-0.5
-1.0004500E+00
-9.9955000E-01
Verify DC current 3 A range
Description Calibrator
setpoint (A)
Lower limit Upper limit
UUT Zero
STANDBY
-1.20E-04
1.20E-04
⅔ scale (+)
2
1.9990800E+00
2.0009200E+00
Half scale (+)
1.5
1.4992800E+00
1.5007200E+00
Half scale (-)
-1.5
-1.5007200E+00
-1.4992800E+00
⅔ scale (-)
-2
-2.0009200E+00
-1.9990800E+00
Digitize current verification
For Digitize DC current verification, you use different connections and procedures to test the 10 µA
and 100 µA ranges and the 1 mA to 3 A ranges than the measure DC current verification.
Digitize DC current 10 µA and 100 µA range verification
To verify digitize DC current accuracy for the 10 µA to 100 µA ranges, you will:
• Apply accurate DC voltage from the calibrator through a precision shunt resistor to the Model
DMM7510 front terminals.
• Sense the voltage across the shunt with a reference DMM.
• Verify that the displayed readings of the Model DMM7510 fall within the calculated reference
DMM voltage and precision shunt limits.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
