10-22 Sweep Operation 2400 Series SourceMeter
®
User’s Manual
Remote sweep operation
Staircase sweep commands
Table 10-3 summarizes remote commands used for linear and log staircase sweep opera-
tion. See Section 18, “Configure voltage and current sweeps,” for more details on these
commands.
Staircase sweep programming example
As an example of linear staircase sweep operation, assume the SourceMeter is to be used
to generate the I-V characteristics of a diode. Many diode tests, such as breakdown voltage
and leakage current, require only single-point measurements. Some, such as quality-
assurance analysis of marginal parts, involve performing a complete I-V sweep for
detailed analysis.
Table 10-3
Linear and log staircase sweep commands
Command Description
:SOURce:CURRent:MODE SWEep
:SOURce:CURRent:STARt <n>
:SOURce:CURRent:STOP <n>
:SOURce:CURRent:STEP <n>
:SOURce:CURRent:CENTer <n>
:SOURce:CURRent:SPAN <n>
:SOURce:VOLTage:MODE SWEep
:SOURce:VOLTage:STARt <n>
:SOURce:VOLTage:STOP <n>
:SOURce:VOLTage:STEP <n>
:SOURce:VOLTage:CENTer <n>
:SOURce:VOLTage:SPAN <n>
:SOURce:SWEep:RANGing <name>
:SOURce:SWEep:SPACing <name>
:SOURce:SWEep:POINts <n>
:SOURce:SWEep:DIREction <name>
Select current source sweep mode.
Specify sweep start current (n = current).
Specify sweep stop current (n = current).
Specify sweep step current (n = current).
Specify sweep center current (n = current).
Specify sweep span current (n = current).
Select voltage source sweep mode.
Specify sweep start voltage (n = voltage).
Specify sweep stop voltage (n = voltage).
Specify sweep step voltage (n = voltage).
Specify sweep center voltage (n = voltage).
Specify sweep span voltage (n = voltage).
Select source ranging (name = BEST, AUTO, or FIXed).
Select sweep scale (name = LINear or LOGarithmic).
Set number of sweep points (n = points).
Set sweep direction. Name = UP (sweep start to stop) or DOWn
(sweep stop to start).
