2400 Series SourceMeter
®
User’s Manual Contact Check Function F-7
Limit test sequence
When enabled, the contact check limit test (Limit 4) is performed before all other limit
tests, as shown in Figure F-4. Figure F-5 shows a flowchart for grading mode limit testing
with contact check limit testing enabled, while Figure F-6 shows a flowchart for sorting
mode limit testing, again with contact check limit testing enabled. See Section 12 for com-
plete details on other limit tests.
Figure F-4
Contact check limit test sequence
Pass
Limit
LO
Fail
Fail
Limit
HI
Pass or Fail on Compliance
Pass
Limit
LO
Fail
Fail
Limit
HI
Limit 1 Test
(Compliance)
Limit 2 Test
(Coarse Limits)
Limit 3, 5-12 Tests
(Fine Limits)
Pass or Fail on Contact Check
Limit 4 Test
(Contact Check)
