Keithley SourceMeter 2430

2400 Series SourceMeter
®
User’s Manual SCPI Command Reference 18-5
:CALCulate2
:LIMit3 Path to control LIMIT 3 test: ✓
:UPPer Configure upper limit: ✓
[:DATA] <n> Specify upper limit (-9.999999e20 to
9.999999e20).
1 ✓✓
[:DATA]? Query upper limit. ✓
:SOURce2 <NRf>
| <NDN>
Specify output fail pattern (0 to 7,
3-bit; 0 to 15, 4-bit).
15 ✓
:SOURce2? Query fail bit pattern.*
:LOWer Configure lower limit: ✓
[:DATA] <n> Specify lower limit (-9.999999e20 to
9.999999e20).
-1 ✓✓
[:DATA]? Query lower limit. ✓
:SOURce2 <NRf>
| <NDN>
Specify output fail pattern for grading
mode. (0 to 7, 3-bit; 0 to 15, 4-bit).
15 ✓
:SOURce2? Query fail bit pattern.*
:PASS Path to specify pass pattern for sorting
mode:
:SOURce2 <NRf>
| <NDN>
Specify output pass pattern (0 to 7,
3-bit; 0 to 15, 4-bit).
15 ✓✓
:SOURce2? Query pass bit pattern.*
:STATe <b> Enable or disable Limit 3 test. OFF ✓✓
:STATe? Query state of Limit 3 test. ✓
:FAIL? Return result of Limit 3 test: 0 (pass) or
1 (fail).
✓
:LIMit4 Path for LIMIT 4 test (contact check option
only).
:SOURce2 <NRf>
| <NDN>
Specify output fail pattern (0 to 7, 3-bit;
0 to 15, 4-bit).
15
:SOURce2? Query fail bit pattern.*
:STATe <b> Enable or disable Limit 4 test. OFF ✓✓
:STATe? Query state of Limit 4 test. ✓
:FAIL? Return result of Limit 4 test: 0 (pass) or
1 (fail).
✓
Table 18-1 (continued)
CALCulate command summary
Command Description
Default
parameter SCPI
Source
memory
