46 6004754F — HK and HK-S Hydraulic Dock Leveler, 3 Button — SafeTFrame
™
January 2009
PARTS LIST , continued
OPTIONAL SUBFRAME RISER KIT
Item Quantity Description Part Number
1 1 4 6004523
    
Fig. 52
2
4x
1x
2x
24" - Subframe with riser
1. Field installed riser kit

4x
