EN
Fe
F22 X X 0.9 Fe CO
Fe
F23 X X 1 Fe CO
Fe
F24 X X 1.2 Fe CO
Ss
S01 X 0.8 Ss-316/308 Ar+2%CO
Ss
S02 X X 0.9 Ss-316/308 Ar+2%CO
Ss
S12 X 0.9 Ss-316/308 Ar+He+CO
Ss
S13 X 1 Ss-316/308 Ar+He+CO
Ss
S14 X 1.2 Ss-316/308 Ar+He+CO
4.4 GETTING STARTED
Step by step for the rst time user
First select your language
NOTE! The default menu language is English. In the following steps you will be able to select
alternative languages
1. Connect mains power and switch on power source. If this is the initial system activation
you may need to press and hold the large orange ON/OFF button on the ARC WIZARD
P65 panel. Top left - Long Press (Approximately 5 seconds).
2. Now press button marked ‘MENU’ to display MAIN MENU listing. There are 7 x items in this
MAIN MENU list. As you select each item in the list, the reference number (Bottom
middle display) will change e.g. 2/7 or 5/7 etc, showing which menu item you have
selected. (You can cycle from rst to last or last to rst in a loop in all menu lists, if you
wish). A black arrow marks your menu item selected.
3. MENU items are selected via the UP-DOWN buttons marked with orange arrows. These
buttons are situated underneath the encoder knob to the right of the panel. Move the
‘black arrow cursor’ up and down the menu lists. Press down arrow button selecting item
5/7 marked LANGUAGE. Press soft key button underneath the word SELECT.
4. Make your language choice as detailed above, and then press the SELECT/SAVE button (right-
hand button next to MENU button). Your language choice is now conrmed and will
remain selected unless you change it later.
New channel job number
FastMig Pulse is designed for production jobs as well as varied specialist operation. Main
welding set-up is made through the ARC WIZARD P65 MENU and recorded to a ‘Channel (Job)
Number’ of your choice.
When you want to weld you simply select the corresponding channel (Job) number on the
wire feed panel PF65 and weld. Only regular needed controls are present on the wire feed unit
panel PF65, making welding easy and convenient.
NOTE! If the machine is new and no welding has been completed before, follow these steps.
A. Switch on power source (May require long press of panel ON/OFF button – 5 sec).
1. Press and select NEW button.
2. Create New Channel – Press SELECT button.
3. Choose weld process and press SELECT button.
B. Then follow the steps from item 4 in the list below.
Editing an existing channel (job) number
1. Press button marked ‘MENU’ to show MAIN MENU listing.
2. SELECT ‘Edit Channel’ – Press SELECT button
3. SELECT ‘Select Weld Curve’ - Press SELECT button
4. Choose and SELECT Process. MIG/1-MIG/Pulse MIG/Double Pulse MIG/ or Curve Number List -
Press SELECT button
5. Choose and SELECT material group – Press SELECT button
6. Choose and SELECT material grade – Press SELECT button
7. Choose and SELECT ller wire diameter – Press SELECT button
18
FastMig Pulse 350, 450 / © Kemppi Oy / 1110
