Removing front tube

Release pressure tension arm. Push the front tube out of its housing with a piece of ller wire.

Wire feed rolls

NOTE! Orange part code colour denotes standard delivery specication.

GT 02 and DuraTorque

ø mm driving pressing

Fe, Ss, Al, V-groove 0.6 W001045 W001046

0.8/0.9 W001047 W001048 (GT 02)

1.0 W000675 W000676 (DuraTorque)

1.2 W000960 W000961

Fe, FC, MC,knurled, V-groove 1.0 W001057 W001058

1.2 W001059 W001060

Fe, FC, MC, Ss, Al,U-groove 1.0 W001067 W001068

1.2 W001069 W001070

For aluminium ller wires select the correct feed roll type from the chart supplied and adjust

for the minimum pressure necessary for reliable ller wire drive without deformation of the

wire itself.

For ux-cored ller wires select a knurled feed roll to achieve better wire grip.

NOTE! Slight slippage is recommended in the case of aluminium ller wires. This ensures that the

soft wire is not deformed and attened and that the feed rolls skid over the soft wire if it stops when

passing through the gun liner or contact tip.

For aluminium and stainless steel ller wires, always use Kemppi DL Teon gun liners.

These liners are especially developed by Kemppi and signicantly reduce friction losses, so

improving welding performance and quality.
