7.2 Gun spare parts
NOTE! Orange part code colour denotes standard delivery specication.
FE 20: 6602003 (3.5 m), 6602004 (5.0 m)
Gas nozzle
(AxBxC)
9580101 60.5 x 18 x 14 mm, standard
958010101 60.5 x 18 x 14 mm, with insulating bush
(= 9580101 + 9591079)
4113470 60.5 x 18 x 14 mm, for spot welding
9580101E 60.5 x 20 x 14 mm, thick wall
Insulating bush
9591010
Contact tip (M6)
9876634 ø 0.6 mm
9876635 0.8 mm
9876633 0.9 mm
9876636 1.0 mm
9876637 1.2 mm
Contact tip
adapter (M6)
9580173
Insulating ring
9591079
Locking spring
4275240
Neck
4153040 45°
Wire liner
4188573 ø 0.6–0.8 mm 3.5 m
W006453 0.9–1.2 mm 3.5 m
W006457 0.8–1.0 mm Al/Ss 3.5 m
W006459 1.0–1.6 mm Al/Ss 3.5 m
4188576 0.6–0.8 mm 5 m
W006454 0.9–1.2 mm 5 m
W006458 0.8–1.0 mm Al/Ss 5 m
W006460 1.0–1.6 mm Al/Ss 5 m
Kempact 251R, 253R, 323R, 181A, 251A, 253A, 323A
28
A
B
C
