Kemppi Minarc Evo 150 Service Manual

Service manual Minarc Evo 150 and 180
Version 1.3
30.9.2015
7
Kemppi Oy
3.3.1. Inner structure
1. Main switch
2. Primary heat sink
3. T001 main transformer
4. Secondary heat sink
5. Secondary choke
6. Remote control socket
7. A001 control card
8. Z001 main circuit card
1.
2.
3.
4.
5.
7.
6.
8.

Kemppi Minarc Evo 150 Specifications

General

Brand	Kemppi
Model	Minarc Evo 150
Category	Welding System
Language	English
