17
PFC card Z004
Components:
Main switch S001
EMI –choke L002
Varistor R002
EMI -filter
Primary rectifier V1
IGBT -transistor
insulated from the heat
sink!!!
Diodes V2 and V3
X2 and X4: control card A002
power supply, 230 Vac
Intermediate circuit
charging resistor and relay
X5 A001
X11 Z002
