Kemppi MLS 2300 ACDC Service Manual

2
Technical data
The device may be repaired only by a person legally authorized
perform electric work!
Connection voltage, 1~ 50/60 Hz 230 V ± 15%
Loadability TIG
40% ED
230 A / 19,2 V (5,7 kVA)
60% ED 200 A / 18,0 V (4,8 kVA)
100% ED
170 A / 16,8 V (3,9 kVA)
Loadability MMA
40% ED
180 A / 27,2 V (6,0 kVA)
60% ED 150 A / 26,0 V (4,8 kVA)
100%
ED
120 A / 24,8 V (3,7 kVA)
Supply cable / fuse 2,5 mm² S - 3,3 m / 16 A slow
Adjustment range
TIG 3 A (AC 5 A) / 10,0 V…230 A / 19,2 V
MMA 10 A / 20,4 V…180 A / 27,2 V
Maximum welding voltage 32 V / 180 A
OCV 50 V
Efficiency 0,8
Power factor 0,99
Open circuit power
TIG 6 W
MMA 180 W
Degree of protection IP 23C
Measures
Length 500 mm
Width 180 mm
Height 260 mm
Weight 15 kg
8 kVA generator can provide maximum output power for the power source however
recommended generator size is 10 kVA
