Page #27 background imageLoading...
Page #27 background image
27
Z004 X15
DC-link negative
Z004 ”heat sink”
DC-link positive
Z004 X4
24 VDC
Measurements
Jumper X12
A002 X2 and X4
230 VAC
A002 X1
24 VDC
22VAC
Z003 X9
Z003 X7
Gnd
Negative dix
Z003 X6
Copper rail
Secondary
heat sink
