Setup functions
AC frequency ** E1
60 Factory setting 60 Hz
50…250 Adjustment range 50…250 Hz
AC waveform ** E2
Sqr Square wave
Sin Sinus wave
Half cycle AC E3
5 Factory setting 5 A
5…20 Adjustment range 5…20 A
AC balance ** E4
-25 Factory setting -25 %
-50…10 Adjustment range -50…10 %
Negative ignition current * E5
100 Factory setting 100 %
100…500 Adjustment range 100…500 % (Limited by
the max. of the power source)
Positive ignition current * E6
50 Factory setting 50 %
30…150 Adjustment range 30…150 % (Limited by
the max. of the power source)
Positive ignition sequence time * E7
10 Factory setting 10 = 0,01 s
0…20 Adjustment range 0…20 = 0,0…0,02 s
Ignition cycle total time * E8
0.20 Factory setting 0,2 s (up to 0A8) / 0,01 s
(since 0A9).
0.01…1,0 Adjustment range 0,01…1,0 s.
MIX TIG cycle time ** E9
0.6 Factory setting
0.1…1,0 Adjustment range 0,1…1,0 s.
*Setting is always on
**Adjustable also by the Quick Setup
***Note panel software version
