Extinguishant Gas Released - Manual
The control panel will indicate confirmation following a successful extinguishant release. If extinguishant release has
been activated by automatic detection the panel will indicate as follows:
• Pre-activated/Activated LED will be illuminated
• Manual Release LED will be illuminated
• Released LED will be illuminated
• Panel buzzer will sound urgently
• LCD will display extinguishant released message
EXTINGUISHANT HAS BEEN RELEASED DO NOT ENTER RISK AREA
FOLLOW SITE PROCEDURES
