Kenwood NX-5200 Service Manual

(No.RA018<Rev.002>)3-5
Electrical parts list
MAIN UNIT
XC1-0331-80(NX-5200_F2,NX-5200_F3,
NX-5200_K2,NX-5200_K3)
XC1-0360-10(NX-5200_K2,NX-5200_K3,
NX-5200_E,NX-5200_E2)
*Note : This part cannot be replaced. There-
fore, this part is not supplied as a service part.
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC20 XC61CC5602N-G IC
IC30 XC6223H331G-G IC
IC31 XC6209B312D-G IC
IC32 XC6215B122N-G IC
IC33 TPS62140RGT IC
IC34 LXDC2HN18F163 IC
IC35 XC6223D331G-G IC
IC36 XC6209B502D-G IC
IC37 BU18TD2WNVX IC
IC38 BU33TD2WNVX IC
IC39 NJM2878F4-33 IC
IC60 TPS61041DRVR IC
IC61 BU33TD2WNVX IC
IC63 XC6209B502D-G IC
IC64 XC6209B502D-G IC
IC65 XC6209B502D-G IC
IC70 BU7242NUX IC
IC80 BU30TD2WNVX IC
IC81 XC6223H331G-G IC
IC82 XC6209B502D-G IC
IC100 SKY72310362LF IC
IC101 OPA170AIDRLR IC
IC102 BU7242NUX IC
IC200 SKY72310362LF IC
IC201 OPA170AIDRLR IC
IC300 UPC2710TB-A IC
IC360 XC8102AA07-G IC
IC400 NJM12904RB1 IC
IC550 BU7295HFV IC
IC551 BU7295HFV IC
IC600 AD9864BCPZRL IC
IC700 CDC3S04YFF IC
IC701 XC8102AA07-G IC
IC702 ------------ IC *Note
IC703 ------------ IC *Note
IC704 S-80135ANPF-G IC
IC705 ------------ IC *Note
IC706 TC7SZ08FE IC
IC708 ------------ IC *Note
IC709 KXCJ9-1008 IC
IC711 BD11600NUX IC
IC712 TC7WH14FK-F IC
IC800 BD1754HFN IC
IC801 NJW4184U2-05 IC
IC802 TC7W53FKF IC
IC803 TC7SPB9306TUF IC
IC804 BD11600NUX IC
IC805 TC7WT126FU-F IC
IC806 TC7SZ08FE IC
IC807 TC7SZ08FE IC
IC850 ------------ IC *Note
IC851 ------------ IC *Note
IC852 74AVC4TD245GU IC
IC853 74AVC4TD245GU IC
IC900 ADS7961SRHB IC
IC901 DAC124S085CIS IC
IC902 TLV32AIC3104I IC
IC903 R2A20178NP IC
IC904 TPA6201A1DRBR IC
IC905 TPA6201A1DRBR IC
IC906 BD11600NUX IC
Q20 EMD12 TRANSISTOR
Q21 SSM6N37FE FET
Q22 SSM6N37FE FET
Q30 SSM3K15AMFV FET
Q31 KTA2012EP TRANSISTOR
Q32 EM6M2 FET
Q33 EM6M2 FET
Q70 LTC014EEBFS8 DIGI TRANSISTOR
Q71 2SB1132(Q,R) TRANSISTOR
Q100 EM6M2 FET
Q101 DSC9A01/T/ TRANSISTOR
Q110 SSM3J15FS FET
Q111 EM6M2 FET
Q160 MCH3914-H/8/ FET
Q180 2SC5108F/Y/ TRANSISTOR
Q181 2SC5108F/Y/ TRANSISTOR
Q200 EM6M2 FET
Q201 DSC9A01/T/ TRANSISTOR
Q210 SSM3J15FS FET
Q211 EM6M2 FET
Q240 MCH3914-H/8/ FET
Q280 2SC5108F/Y/ TRANSISTOR
Q281 2SC5108F/Y/ TRANSISTOR
Q310 2SK3077F FET
Q320 RD01MUS2BT113 FET
Q330 RD07MUS2BT214 FET
Q390 LSCR523EBFS8 TRANSISTOR
Q400 LTC023JEBFS8 DIGI TRANSISTOR
Q401 SSM3K15AMFV FET
Q402 SSM3K15AMFV FET
Q403 EMD9 TRANSISTOR
Q404 SSM3J15FS FET
Q500 BB506CFS-H FET
Q530 3SK318 FET
Q580 2SC5108F/Y/ TRANSISTOR
Q600 MCH3914-H/8/ FET
Q601 LTC023JEBFS8 DIGI TRANSISTOR
Q602 LSCR523EBFS8 TRANSISTOR
Q660 2SC5066F/O/ TRANSISTOR
Q670 BB506CFS-H FET
Q700 2SC4617/S/ TRANSISTOR
Q701 SSM3K15AMFV FET
Q702 LTC014EEBFS8 DIGI TRANSISTOR
Q703 SSM6N37FE FET
Q800 SSM3K15AMFV FET
Q801 EMD9 TRANSISTOR
Q850 SSM3K15AMFV FET
D1 1SR154-400 DIODE
D2 DA3S101F DIODE ARRAY
D20 DAN222 DIODE ARRAY
D30 RB520SM-30 DIODE
D60 DB2J40700 DIODE
D100 EDZV8.2B ZENER DIODE
D101 1SS400SM DIODE
D160 SMV1705-079LF VARI CAP DIODE
D161 SMV1801-079LF VARI CAP DIODE
D162 SMV1801-079LF VARI CAP DIODE
D163 SMV1801-079LF VARI CAP DIODE
D164 SMV1130-079LF VARI CAP DIODE
D200 EDZV8.2B ZENER DIODE
D201 1SS400SM DIODE
D240 SMV1270-079LF VARI CAP DIODE
D241 SMV1801-079LF VARI CAP DIODE
D242 SMV1801-079LF VARI CAP DIODE
D243 SMV1801-079LF VARI CAP DIODE
D350 RN142S DIODE
D351 RN142S DIODE
D370 RN142S DIODE
D371 RN142S DIODE
D390 DZ2S056(M) ZENER DIODE
D520 BBY58-02V VARI CAP DIODE
D521 BBY58-02V VARI CAP DIODE
D530 BBY58-02V VARI CAP DIODE
D531 BBY58-02V VARI CAP DIODE
D600 SMV1705-079LF VARI CAP DIODE
 Symbol No. Part No. Part Name Description Local

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
