(No.RA018<Rev.002>)3-7

C191 CC73HCH1H270G C CAPACITOR 27pF 50V G

C192 CC73HCH1H060B C CAPACITOR 6pF 50V B

C193 CC73HCH1H060B C CAPACITOR 6pF 50V B

C194 CC73HCH1H030B C CAPACITOR 3pF 50V B

C195 CC73HCH1H330G C CAPACITOR 33pF 50V G

C196 CC73HCH1H120G C CAPACITOR 12F 50V G

C197 CC73HCH1H120G C CAPACITOR 12F 50V G

C200 CK73HB1H103K C CAPACITOR 10000pF 50V K

C203 CC73HCH1H100B C CAPACITOR 10pF 50V B

C204 CK73HB1H103K C CAPACITOR 10000pF 50V K

C206 CK73HB1H103K C CAPACITOR 10000pF 50V K

C207 CC73JCH1H101J C CAPACITOR 100pF 50V J

C208 CC73JCH1H101J C CAPACITOR 100pF 50V J

C209 CC73JCH1H101J C CAPACITOR 100pF 50V J

C210 CC73JCH1H101J C CAPACITOR 100pF 50V J

C211 C93-1959-05 C CAPACITOR 0.1uF 16V

C212 CC73JCH1H101J C CAPACITOR 100pF 50V J

C213 CC73HCH1H101J C CAPACITOR 100pF 50V J

C214 C93-1959-05 C CAPACITOR 0.1uF 16V

C215 CC73JCH1H101J C CAPACITOR 100pF 50V J

C216 CK73HBB1H472K C CAPACITOR 4700pF 50V K

C217 CK73HB1H103K C CAPACITOR 10000pF 50V K

C218 CC73HCH1H330G C CAPACITOR 33pF 50V G

C219 CC73JCH1H101J C CAPACITOR 100pF 50V J

C220 CK73GB1H105K C CAPACITOR 1uF 50V K

C222 C93-1967-05 C CAPACITOR 470pF 50V

C223 CS77BP1A4R7M TA E CAPACITOR 4.7uF 10V M

C224 C93-1967-05 C CAPACITOR 470pF 50V

C240 CK73FB1E224K C CAPACITOR 0.22uF 25V K

C241 CS77ABE1D100M TA E CAPACITOR 10uF 20V M

C243 CK73HB1A105K C CAPACITOR 1uF 10V K

C244 CC73HCH1H680J C CAPACITOR 68pF 50V J

C246 CC73HCH1H270G C CAPACITOR 27pF 50V G

C248 CC73HCH1H120G C CAPACITOR 12F 50V G

C249 CC73HCH1H120G C CAPACITOR 12F 50V G

C250 CK73HB1H103K C CAPACITOR 10000pF 50V K

C251 C93-1967-05 C CAPACITOR 470pF 50V

C252 CC73HCH1H0R5B C CAPACITOR 0.5pF 50V B

C253 CK73HB1A105K C CAPACITOR 1uF 10V K

C255 CC73FSL1H473J C CAPACITOR 0.047uF 50V J

C281 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C282 CK73HBB1H471K C CAPACITOR 470pF 50V K

C283 CC73HCH1H150G C CAPACITOR 15pF 50V G

C284 CC73HCH1H220G C CAPACITOR 22pF 50V G

C285 CK73HBB1H471K C CAPACITOR 470pF 50V K

C286 CC73HCH1H100B C CAPACITOR 10pF 50V B

C287 CC73HCH1H060B C CAPACITOR 6pF 50V B

C288 CC73HCH1H030B C CAPACITOR 3pF 50V B

C289 CC73HCH1H330G C CAPACITOR 33pF 50V G

C290 CC73HCH1H100B C CAPACITOR 10pF 50V B

C291 CC73HCH1H220G C CAPACITOR 22pF 50V G

C292 CC73HCH1H100B C CAPACITOR 10pF 50V B

C293 CC73HCH1H100B C CAPACITOR 10pF 50V B

C294 CC73HCH1H030B C CAPACITOR 3pF 50V B

C295 CC73HCH1H220G C CAPACITOR 22pF 50V G

C296 CC73HCH1H240G C CAPACITOR 24pF 50V G

C297 CC73HCH1H080B C CAPACITOR 8pF 50V B

C300 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C301 CC73HCH1H020B C CAPACITOR 2pF 50V B

C303 CC73HCH1H100B C CAPACITOR 10pF 50V B

C304 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C305 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C306 CC73HCH1H330G C CAPACITOR 33pF 50V G

C307 CC73HCH1H101J C CAPACITOR 100pF 50V J

C310 CC73HCH1H150G C CAPACITOR 15pF 50V G

C311 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C313 CC73HCH1H560J C CAPACITOR 56pF 50V J

C315 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C316 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C317 CK73HBB1H471K C CAPACITOR 470pF 50V K

C318 CC73HCH1H150G C CAPACITOR 15pF 50V G

C320 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C321 CK73HB1E104K C CAPACITOR 0.10uF 25V K

C322 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C323 CC73HCH1H220J C CAPACITOR 22pF 50V J

C325 CC73HCH1H220G C CAPACITOR 22pF 50V G

C326 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C327 CC73HCH1H390J C CAPACITOR 39pF 50V J



Symbol No.

Part No. Part Name Description Local

C328 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C331 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C334 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C338 CC73HCH1H151J C CAPACITOR 150pF 50V J

C339 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C340 CC73GCH1H120G C CAPACITOR 12pF 50V G

C341 CK73GB1E104K C CAPACITOR 0.1uF 25V K

C342 CC73GCH1H220G C CAPACITOR 22pF 50V G

C343 CK73HB1H103K C CAPACITOR 10000pF 50V K

C344 CC73GCH1H470G C CAPACITOR 47pF 50V G

C345 CC73GCH1H030B C CAPACITOR 3pF 50V B

C347 CC73GCH1H680G C CAPACITOR 68pF 50V G

C348 CC73GCH1H010B C CAPACITOR 1pF 50V B

C350 CC73GCH1H1R5B C CAPACITOR 1.5pF 50V B

C351 CC73GCH1H180G C CAPACITOR 18pF 50V G

C352 CK73GBB1H102K C CAPACITOR 1000pF 50V K

C353 CC73GCH1H070B C CAPACITOR 7pF 50V B

C354 CC73GCH1H070B C CAPACITOR 7pF 50V B

C355 CC73GCH1H180G C CAPACITOR 18pF 50V G

C356 CC73GCH1H090B C CAPACITOR 9pF 50V B

C357 CC73GCH1H150G C CAPACITOR 15pF 50V G

C358 CC73GCH1H060B C CAPACITOR 6pF 50V B

C359 CC73GCH1H090B C CAPACITOR 9pF 50V B

C360 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C361 CC73JCH1H101J C CAPACITOR 100pF 50V J

C362 CC73JCH1H101J C CAPACITOR 100pF 50V J

C363 CC73GCH1H180G C CAPACITOR 18pF 50V G

C365 CC73GCH1H100B C CAPACITOR 10pF 50V B

C369 CC73HCH1H150G C CAPACITOR 15pF 50V G

C370 CC73HCH1H150G C CAPACITOR 15pF 50V G

C372 CK73GBB1H102K C CAPACITOR 1000pF 50V K

C378 CC73GCH1H181J C CAPACITOR 180pF 50V J

C390 C93-1967-05 C CAPACITOR 470pF 50V

C391 CC73JCH1H101J C CAPACITOR 100pF 50V J

C392 CC73HCH1H101J C CAPACITOR 100pF 50V J

C400 CK73HBB1H471K C CAPACITOR 470pF 50V K

C402 CK73GB1C563K C CAPACITOR 0.056uF 16V K

C404 CK73HBB1H471K C CAPACITOR 470pF 50V K

C408 CK73HBB1H152K C CAPACITOR 1500pF 50V K

C409 CK73HBB1H152K C CAPACITOR 1500pF 50V K

C410 CK73HBB1H471K C CAPACITOR 470pF 50V K

C412 CC73JCH1H101J C CAPACITOR 100pF 50V J

C413 CC73JCH1H101J C CAPACITOR 100pF 50V J

C501 CK73HB1H103K C CAPACITOR 10000pF 50V K

C503 CK73HB1H103K C CAPACITOR 10000pF 50V K

C506 CC73HCH1H120G C CAPACITOR 12F 50V G

C507 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C508 CK73HB1H103K C CAPACITOR 10000pF 50V K

C510 CC73HCH1H030B C CAPACITOR 3pF 50V B

C511 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C512 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C515 CC73HCH1H060B C CAPACITOR 6pF 50V B

C520 CC73HCH1H070B C CAPACITOR 7pF 50V B

C521 CC73HCH1H680G C CAPACITOR 68pF 50V G

C523 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C524 CC73HCH1H1R5B C CAPACITOR 1.5pF 50V B

C525 CC73HCH1H270G C CAPACITOR 27pF 50V G

C526 CC73HCH1H010B C CAPACITOR 1pF 50V B

C530 CK73HB1E104K C CAPACITOR 0.10uF 25V K

C531 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C532 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C533 CK73HB1H103K C CAPACITOR 10000pF 50V K

C534 CC73HCH1H010B C CAPACITOR 1pF 50V B

C535 CC73HCH1H030B C CAPACITOR 3pF 50V B

C536 CK73GB1E105K C CAPACITOR 1uF 25V K

C537 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C538 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C539 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C540 CC73HCH1H0R5B C CAPACITOR 0.5pF 50V B

C541 CK73HBB1H102K C CAPACITOR 1000pF 50V K

C543 CC73HCH1H010B C CAPACITOR 1pF 50V B

C544 CC73HCH1H080B C CAPACITOR 8pF 50V B

C545 CC73HCH1H270G C CAPACITOR 27pF 50V G

C547 CC73HCH1H270G C CAPACITOR 27pF 50V G

C549 CC73HCH1H470G C CAPACITOR 47pF 50V G

C550 CK73HB1H103K C CAPACITOR 10000pF 50V K

C551 CK73HB1H103K C CAPACITOR 10000pF 50V K

C552 CK73HB1H103K C CAPACITOR 10000pF 50V K



Symbol No.

Part No. Part Name Description Local
