Kenwood NX-5200 Service Manual

(No.RA018<Rev.002>)3-11
R206 RK73HB1J100J MG RESISTOR 10 Ω 1/16W J
R207 RK73HB1J102J MG RESISTOR 1k Ω 1/16W J
R208 RK73HB1J102J MG RESISTOR 1k Ω 1/16W J
R209 RK73HB1J393J MG RESISTOR 39k Ω 1/16W J
R210 RK73HB1J124J MG RESISTOR 120k Ω 1/16W J
R211 RK73HB1J100J MG RESISTOR 10
Ω 1/16W J
R212 RK73HB1J472J MG RESISTOR 4.7k
Ω 1/16W J
R213 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R214 RK73HB1J106J MG RESISTOR 10M Ω 1/16W J
R215 RK73HB1J470J MG RESISTOR 47 Ω 1/16W J
R216 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R217 RK73HB1J103J MG RESISTOR 10k Ω 1/16W J
R230 RK73HB1J473J MG RESISTOR 47k Ω 1/16W J
R231 RK73HB1J474J MG RESISTOR 470k Ω 1/16W J
R232 RK73HB1J474J MG RESISTOR 470k Ω 1/16W J
R240 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R241 RK73HB1J181J MG RESISTOR 180 Ω 1/16W J
R242 RK73HB1J105J MG RESISTOR 1M Ω 1/16W J
R243 RK73HB1J121J MG RESISTOR 120 Ω 1/16W J
R244 RK73HB1J103J MG RESISTOR 10k Ω 1/16W J
R247 RN73HH1J331D MF RESISTOR 330
Ω 1/16W D
R248 RN73HH1J220D MF RESISTOR 22
Ω 1/16W D
R249 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R250 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R281 RK73HB1J473J MG RESISTOR 47k Ω 1/16W J
R283 RK73HB1J102J MG RESISTOR 1k Ω 1/16W J
R285 RK73HB1J563J MG RESISTOR 56k Ω 1/16W J
R287 RK73HB1J561J MG RESISTOR 560 Ω 1/16W J
R288 RK73HB1J560J MG RESISTOR 56 Ω 1/16W J
R290 RK73HB1J101J MG RESISTOR 100 Ω 1/16W J
R291 RK73HB1J120J MG RESISTOR 12 Ω 1/16W J
R292 RK73HB1J471J MG RESISTOR 470 Ω 1/16W J
R293 RK73HB1J471J MG RESISTOR 470 Ω 1/16W J
R294 RK73HB1J180J MG RESISTOR 18 Ω 1/16W J
R295 RK73HB1J271J MG RESISTOR 270 Ω 1/16W J
R296 RK73HB1J271J MG RESISTOR 270 Ω 1/16W J
R300 RK73HB1J101J MG RESISTOR 100 Ω 1/16W J
R301 RK73HB1J680J MG RESISTOR 68 Ω 1/16W J
R302 RK73HB1J101J MG RESISTOR 100 Ω 1/16W J
R303 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R304 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R311 RK73HB1J680J MG RESISTOR 68 Ω 1/16W J
R313 RK73HB1J101J MG RESISTOR 100 Ω 1/16W J
R314 RK73HB1J102J MG RESISTOR 1k Ω 1/16W J
R315 RK73HB1J270J MG RESISTOR 27 Ω 1/16W J
R316 RK73HB1J222J MG RESISTOR 2.2k Ω 1/16W J
R317 RK73HB1J331J MG RESISTOR 330 Ω 1/16W J
R321 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R323 RK73HB1J332J MG RESISTOR 3.3k Ω 1/16W J
R324 RK73HB1J470J MG RESISTOR 47
Ω 1/16W J
R325 RK73HB1J392J MG RESISTOR 3.9k Ω 1/16W J
R326 RK73HB1J101J MG RESISTOR 100
Ω 1/16W J
R327 RK73HB1J000J MG RESISTOR 0
Ω 1/16W J
R328 RK73GB2A000J MG RESISTOR 0 Ω 1/10W J
R330 RK73HB1J100J MG RESISTOR 10
Ω 1/16W J
R331 RK73HB1J392J MG RESISTOR 3.9k
Ω 1/16W J
R334 RK73HB1J332J MG RESISTOR 3.3k Ω 1/16W J
R350 RK73GB2A823J MG RESISTOR 82k
Ω 1/10W J
R351 RK73HB1J101J MG RESISTOR 100 Ω 1/16W J
R352 RK73HB1J101J MG RESISTOR 100
Ω 1/16W J
R360 RK73HB1J271J MG RESISTOR 270
Ω 1/16W J
R361 RK73HB1J271J MG RESISTOR 270 Ω 1/16W J
R362 RK73HB1J102J MG RESISTOR 1k
Ω 1/16W J
R372 RK73GB2A000J MG RESISTOR 0
Ω 1/10W J
R390 RK73HB1J273J MG RESISTOR 27k Ω 1/16W J
R391 RK73HB1J473J MG RESISTOR 47k
Ω 1/16W J
R392 RK73HB1J473J MG RESISTOR 47k
Ω 1/16W J
R393 RK73HB1J470J MG RESISTOR 47
Ω 1/16W J
R394 RK73HB1J000J MG RESISTOR 0
Ω 1/16W J
R400 R92-3756-05 MG RESISTOR 0.22 Ω 1/3W
R401 RK73JB1H103J MG RESISTOR 10
Ω 1/20W J
R402 R92-3756-05 MG RESISTOR 0.22
Ω 1/3W
R403 RK73HB1J390J MG RESISTOR 39 Ω 1/16W J
R404 RK73HH1J472D MG RESISTOR 4.7k
Ω 1/16W D
R405 RK73HH1J472D MG RESISTOR 4.7k
Ω 1/16W D
R406 RK73HB1J471J MG RESISTOR 470 Ω 1/16W J
R407 RK73HH1J333D MG RESISTOR 33k
Ω 1/16W D
R408 RK73HH1J562D MG RESISTOR 5.6k
Ω 1/16W D
 Symbol No. Part No. Part Name Description Local
R409 RK73HB1J470J MG RESISTOR 47 Ω 1/16W J
R410 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R412 RK73HB1J332J MG RESISTOR 3.3k Ω 1/16W J
R414 RK73HB1J822J MG RESISTOR 8.2k Ω 1/16W J
R416 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R417 RK73HB1J223J MG RESISTOR 22k
Ω 1/16W J
R418 RK73HB1J223J MG RESISTOR 22k
Ω 1/16W J
R420 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R422 RK73JB1H102J MG RESISTOR 1 Ω 1/20W J
R424 RK73HH1J682D MG RESISTOR 6.8k Ω 1/16W D
R425 RK73HB1J152J MG RESISTOR 1.5k Ω 1/16W J
R500 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R501 RK73HB1J470J MG RESISTOR 47 Ω 1/16W J
R502 RK73HB1J471J MG RESISTOR 470 Ω 1/16W J
R503 RK73HB1J181J MG RESISTOR 180 Ω 1/16W J
R505 RK73HB1J124J MG RESISTOR 120k Ω 1/16W J
R507 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R508 RK73HB1J154J MG RESISTOR 150k Ω 1/16W J
R520 RK73HB1J105J MG RESISTOR 1M Ω 1/16W J
R521 RK73HB1J105J MG RESISTOR 1M Ω 1/16W J
R530 RK73HB1J102J MG RESISTOR 1k
Ω 1/16W J
R532 RK73HB1J680J MG RESISTOR 68
Ω 1/16W J
R533 RK73HB1J221J MG RESISTOR 220 Ω 1/16W J
R536 RK73HB1J124J MG RESISTOR 120k Ω 1/16W J
R537 RK73HB1J154J MG RESISTOR 150k Ω 1/16W J
R538 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R539 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R540 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R541 RK73GB2A470J MG RESISTOR 47 Ω 1/10W J
R550 RK73HB1J103J MG RESISTOR 10k Ω 1/16W J
R551 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R552 RK73HB1J563J MG RESISTOR 56k Ω 1/16W J
R553 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R554 RK73HB1J103J MG RESISTOR 10k Ω 1/16W J
R555 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R557 RK73HB1J563J MG RESISTOR 56k Ω 1/16W J
R558 RK73HB1J104J MG RESISTOR 100k Ω 1/16W J
R564 RK73HB1J000J MG RESISTOR 0 Ω 1/16W J
R566 RK73HB1J334J MG RESISTOR 330k Ω 1/16W J
R567 RK73HB1J564J MG RESISTOR 560k Ω 1/16W J
R580 RK73HB1J222J MG RESISTOR 2.2k Ω 1/16W J
R581 RK73HB1J470J MG RESISTOR 47 Ω 1/16W J
R582 RK73HB1J331J MG RESISTOR 330 Ω 1/16W J
R583 RK73HB1J682J MG RESISTOR 6.8k Ω 1/16W J
R584 RK73HB1J103J MG RESISTOR 10k Ω 1/16W J
R588 RK73GB2A151J MG RESISTOR 150 Ω 1/10W J
R600 RK73HB1J102J MG RESISTOR 1k Ω 1/16W J
R601 RK73HB1J681J MG RESISTOR 680 Ω 1/16W J
R602 RK73JB1H103J MG RESISTOR 10 Ω 1/20W J
R603 RK73HB1J561J MG RESISTOR 560
Ω 1/16W J
R604 RK73HB1J220J MG RESISTOR 22 Ω 1/16W J
R605 RK73HB1J182J MG RESISTOR 1.8k
Ω 1/16W J
R606 RK73HB1J562J MG RESISTOR 5.6k
Ω 1/16W J
R607 RK73HB1J471J MG RESISTOR 470 Ω 1/16W J
R608 RK73JB1H472J MG RESISTOR 4.7k
Ω 1/20W J
R609 RK73HB1J104J MG RESISTOR 100k
Ω 1/16W J
R610 RK73HB1J470J MG RESISTOR 47 Ω 1/16W J
R660 RK73HB1J103J MG RESISTOR 10k
Ω 1/16W J
R661 RK73HB1J101J MG RESISTOR 100 Ω 1/16W J
R662 RK73HB1J274J MG RESISTOR 270k
Ω 1/16W J
R663 RK73HB1J271J MG RESISTOR 270
Ω 1/16W J
R664 RK73HB1J180J MG RESISTOR 18 Ω 1/16W J
R665 RK73HB1J271J MG RESISTOR 270
Ω 1/16W J
R670 RK73HB1J470J MG RESISTOR 47
Ω 1/16W J
R671 RK73HB1J681J MG RESISTOR 680 Ω 1/16W J
R672 RK73HB1J104J MG RESISTOR 100k
Ω 1/16W J
R673 RK73HB1J563J MG RESISTOR 56k
Ω 1/16W J
R674 RK73HB1J823J MG RESISTOR 82k
Ω 1/16W J
R675 RK73HB1J333J MG RESISTOR 33k
Ω 1/16W J
R677 RK73HB1J101J MG RESISTOR 100 Ω 1/16W J
R700 RK73HB1J102J MG RESISTOR 1k
Ω 1/16W J
R701 RK73HB1J000J MG RESISTOR 0
Ω 1/16W J
R702 RK73HB1J100J MG RESISTOR 10 Ω 1/16W J
R703 RK73HB1J000J MG RESISTOR 0
Ω 1/16W J
R704 RK73HB1J102J MG RESISTOR 1k
Ω 1/16W J
R705 RK73HB1J153J MG RESISTOR 15k Ω 1/16W J
R706 RK73HB1J333J MG RESISTOR 33k
Ω 1/16W J
R707 RK73HB1J100J MG RESISTOR 10
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
