Kenwood NX-5200 Service Manual

(No.RA018<Rev.002>)3-13
L38 LB73H0AV-002 CHIP FERRITE
L39 LB73G0BJ-002 CHIP FERRITE
L40 LB73H0AV-002 CHIP FERRITE
L60 L41-1502-70 CHIP INDUCTOR
L61 LB73H0AV-002 CHIP FERRITE
L81 LB73G0AK-001 CHIP FERRITE
L100 LB73H0AV-003 CHIP FERRITE
L101 LB73H0AY-004 CHIP FERRITE
L140 LB73H0AV-003 CHIP FERRITE
L160 LK73G0AQ100K M.CHIP INDUCTOR 10uH
L161 LK73G0AQ3R3K M.CHIP INDUCTOR 3.3uH
L162 LK73G0AQ3R3K M.CHIP INDUCTOR 3.3uH
L163 LK73G0AFR12J M.CHIP INDUCTOR 0.12uH
L164 L41-5675-43 CHIP INDUCTOR
L165 LB73H0AY-004 CHIP FERRITE
L166 LK73G0AQ3R3K M.CHIP INDUCTOR 3.3uH
L180 LK73H0AMR12J M.CHIP INDUCTOR 0.12uH
L181 LK73G0AF56NJ M.CHIP INDUCTOR 56nH
L182 LK73H0AM5N6S M.CHIP INDUCTOR 5.6nH
L184 LK73H0AM5N6S M.CHIP INDUCTOR 5.6nH
L185 LK73H0AM82NJ
M.CHIP INDUCTOR 82nH
L186 LK73H0AM82NJ
M.CHIP INDUCTOR 82nH
L187 LK73H0AM12NJ M.CHIP INDUCTOR 12nH
L200 LB73H0AV-003 CHIP FERRITE
L240 LB73H0AV-003 CHIP FERRITE
L241 LK73G0AQ100K M.CHIP INDUCTOR 10uH
L242 LK73G0AFR22J M.CHIP INDUCTOR 0.22uH
L243 LK73G0AFR22J M.CHIP INDUCTOR 0.22uH
L244 LK73G0AFR27J M.CHIP INDUCTOR 0.27uH
L245 L41-3375-43 CHIP INDUCTOR
L247 LK73G0AQ3R3K M.CHIP INDUCTOR 3.3uH
L248 LB73H0AY-004 CHIP FERRITE
L280 LK73H0AM68NJ M.CHIP INDUCTOR 68nH
L281 LK73G0AF39NJ M.CHIP INDUCTOR 39nH
L282 L40-3363-71 CHIP INDUCTOR
L284 LK73H0AM4N7S M.CHIP INDUCTOR 4.7nH
L285 LK73H0AM56NJ M.CHIP INDUCTOR 56nH
L286 LK73H0AM56NJ M.CHIP INDUCTOR 56nH
L287 LK73H0AM10NJ M.CHIP INDUCTOR 10nH
L303 LK73G0AF68NJ M.CHIP INDUCTOR 68nH
L310 LK73H0AM47NJ M.CHIP INDUCTOR 47nH
L311 LK73H0AM68NJ M.CHIP INDUCTOR 68nH
L312 LK73H0AM82NJ M.CHIP INDUCTOR 82nH
L313 LB73G0BD-005 CHIP FERRITE
L320 LK73H0AM47NJ M.CHIP INDUCTOR 47nH
L322 LR79Z0CAR10J CHIP INDUCTOR 0.1uH
L323 LB73F0AW-002 CHIP FERRITE
L330 LK73G0AF8N2J M.CHIP INDUCTOR 8.2nH
L331 LR79Z0DC27N9J CHIP INDUCTOR 27.9nH
L332 LB73F0AW-002 CHIP FERRITE
L333 LK73G0AF6N8J
M.CHIP INDUCTOR 6.8nH
L340 LR79Z0DC16N7J CHIP INDUCTOR 16.7nH
L341 LR79Z0DC22NJ CHIP INDUCTOR 22nH
L350 LR79Z0DD12N2J CHIP INDUCTOR 12.2nH
L351 LR79Z0DD43N6J CHIP INDUCTOR 43.6nH
L352 LR79Z0DD43N6J CHIP INDUCTOR 43.6nH
L353 LR79Z0DD43N6J CHIP INDUCTOR 43.6nH
L360 LR73Z0AE2R2J CHIP INDUCTOR 2.2uH
L370 LR79Z0DC45N5J CHIP INDUCTOR 45.5nH
L500 LR77Z0AER56J CHIP INDUCTOR 0.56uH
L501 LB73G0BD-005 CHIP FERRITE
L502 LR77Z0AER27J CHIP INDUCTOR 0.27uH
L503 L41-1285-53 CHIP INDUCTOR
L504 L41-2285-14 CHIP INDUCTOR
L520 L41-6878-14 CHIP INDUCTOR
L530 L41-6878-14 CHIP INDUCTOR
L532 L41-6878-14 CHIP INDUCTOR
L535 L41-8278-14 CHIP INDUCTOR
L580 LK73H0AM33NJ
M.CHIP INDUCTOR 33nH
L581 LK73H0AM33NJ M.CHIP INDUCTOR 33nH
L582 LK73G0AF82NJ
M.CHIP INDUCTOR 82nH
L600 LK73G0AQ100K
M.CHIP INDUCTOR 10uH
L601 LB73H0AV-003 CHIP FERRITE
L602 LB73H0AV-003 CHIP FERRITE
L603 L41-3988-55 CHIP INDUCTOR
L604 LK73G0AFR27J M.CHIP INDUCTOR 0.27uH
L605 LB73H0AV-003 CHIP FERRITE
L606 L41-4798-14 CHIP INDUCTOR
 Symbol No. Part No. Part Name Description Local
L607 LB73H0AV-003 CHIP FERRITE
L608 LB73H0AV-003 CHIP FERRITE
L609 L41-1885-53 CHIP INDUCTOR
L610 LK73G0AQ100K M.CHIP INDUCTOR 10uH
L611 LK73G0AQ100K M.CHIP INDUCTOR 10uH
L612 L41-2285-53 CHIP INDUCTOR
L613 LB73H0AV-003 CHIP FERRITE
L614 LB73H0AV-003 CHIP FERRITE
L660 LK73G0AQR33K M.CHIP INDUCTOR 0.33uH
L661 LB73H0AV-002 CHIP FERRITE
L662 LK73G0AQR82K M.CHIP INDUCTOR 0.82uH
L670 LK73G0AQR82K M.CHIP INDUCTOR 0.82uH
L671 LK73G0AQR47K M.CHIP INDUCTOR 0.47uH
L672 LB73H0AV-002 CHIP FERRITE
L673 LK73G0ASR47J M.CHIP INDUCTOR 470nH
L674 LK73G0ASR47J M.CHIP INDUCTOR 470nH
L700 LB73H0AV-003 CHIP FERRITE
L701 LK73G0AQ4R7K M.CHIP INDUCTOR 4.7uH
L702 LB73H0AV-002 CHIP FERRITE
L703 LB73H0AV-002 CHIP FERRITE
L704 LB73H0AV-002 CHIP FERRITE
L705 LB73G0AM-004 CHIP FERRITE
L706 L92-1101-05 CHIP FERRITE
L708 L92-1101-05 CHIP FERRITE
L710 LB73G0AK-001 CHIP FERRITE
L711 LB73G0AK-001 CHIP FERRITE
L717 LB73G0AK-001 CHIP FERRITE
L719 LB73G0AK-001 CHIP FERRITE
L800 LB73G0AK-001 CHIP FERRITE
L808 LB73G0AK-001 CHIP FERRITE
L809 LB73G0AM-004 CHIP FERRITE
L810 LB73G0AM-004 CHIP FERRITE
L811 LB73H0AV-002 CHIP FERRITE
L812 LB73H0AV-002 CHIP FERRITE
L813 LB73G0AM-004 CHIP FERRITE
L814 LB73H0AV-002 CHIP FERRITE
L815 LB73G0AM-004 CHIP FERRITE
L850 L92-0487-05 CHIP FERRITE
L851 L92-0487-05 CHIP FERRITE
L852 LK73H0AM10NJ M.CHIP INDUCTOR 10nH
L853 L79-1985-05 FILTER
L854 L92-0487-05 CHIP FERRITE
L855 L79-1987-05 FILTER
L856 LK73H0AM6N8J M.CHIP INDUCTOR 6.8nH
L857 L79-1985-05 FILTER
L858 L41-3965-55 CHIP INDUCTOR
L859 L41-3965-55 CHIP INDUCTOR
L861 L92-0487-05 CHIP FERRITE
L862 L92-0487-05 CHIP FERRITE
L863 L40-2263-71 CHIP INDUCTOR
L902 LB73H0AV-002 CHIP FERRITE
L903 LB73G0AM-004 CHIP FERRITE
L904 LB73G0AM-004 CHIP FERRITE
A30 W02-3785-05 DC-DC CONVERTER
CN1 G0B-0023-00 EARTH SPRING
CN3 G0B-0023-00 EARTH SPRING
CN4 E40-6970-05 PIN ASSY
CN7 J19-5386-05 HOLDER
CN8 E40-6883-05 F.C.CONNECTOR
CN9 E40-6962-05 F.C.CONNECTOR
CN10 E40-6720-05 SOCKET FOR PIN
CN11 E40-6720-05 SOCKET FOR PIN
CN12 E41-3167-05 F.C.CONNECTOR
CN13 E41-1486-05 PIN ASSY
CN14 G0B-0005-00 EARTH SPRING
CN15 G0B-0005-00 EARTH SPRING
CN16 G0B-0005-00 EARTH SPRING
CN17 G0B-0005-00 EARTH SPRING
CN18 G0B-0005-00 EARTH SPRING
CN20 G0B-0005-00 EARTH SPRING
CN21 G0B-0005-00 EARTH SPRING
CN301 E23-1278-05 TERMINAL
CN602 E23-1278-05 TERMINAL
CN603 G0B-0002-00 EARTH SPRING
CN912 G0B-0005-00 EARTH SPRING
CP100 RK74HB1J100J NET RESISTOR 10
Ω 1/16W J
CP200 RK74HB1J100J NET RESISTOR 10
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
