Kenwood NX-5200 Service Manual

(No.RA018<Rev.002>)1-33
3.3.7 Assembly Information (Sheet/Cushion)
When “Main Parts” is changed (ordered), “Assembled Sheet / Cushion” should also be changed (ordered) together.
The Sticker and Sheet etc are non-reusable parts. It requires the new one to get the radio’s performance after repairs.
For example, when “Plastic Cabinet (A0C-0001-00 (F3,K3,E)/ A0C-0002-00 (F2,K2,E2))” is changed, “Badge (B4D-0002-00)”, ”Fi-
brous Sheet (G1A-0001-00)”, “Sheet (G1B-0074-00)”, “Spacer (J3K-0003-00)” and “Knob (K2K-0013-00)” should be ordered and
changed together because Badge (B4D-0002-00), Fibrous Sheet (G1A-0001-00), Sheet (G1B-0074-00), Spacer (J3K-0003-00) and
Knob (K2K-0013-00) are non-reusable.
Main Parts Assembled Sheet/ Cushion
Part Name Part Number Part Name Part Number Remark
Plastic Cabinet (F3,K3,E)
Plastic Cabinet (F2,K2,E2)
A0C-0001-00
A0C-0002-00
Badge B4D-0002-00 “KENWOOD” is printed.
Fibrous Sheet (SP) G1A-0001-00
Sheet (LCD) G1B-0074-00
Spacer (2CH) J3K-0003-00
Knob (2CH) K2K-0013-00
Rear Panel A8A-0005-00 Sheet (Air) G11-4440-04
Terminal Block E7C-0001-00 Terminal Sticker B4C-0105-00
Cover (OP board) F0G-0005-00 Cushion (Cover) G1D-0062-00
Shielding Cover (MPU) F1B-0005-00 Sheet (Insulating) G1B-0031-00
Shielding Cover (LCD) F1B-0006-00 Cushion (LCD/Front) G1D-0009-00
Holder (F3,K3,E) J1K-0004-10 Cushion (20-pin Connector) G1D-0021-00
FPC (UNIV) J87-0056-05 R.Receptacle E58-0532-05
FPC (PTT) J87-0057-05 Sheet (PTT) G1B-0016-00
FPC (VOL, SEL, ECM) J87-0058-05 Sheet (Conducting) G11-4459-04
Cushion G1D-0025-00
Speaker T0H-0002-00 Rubber Cushion (SP) G1B-0045-10

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
