Kenwood NX-5200 Service Manual

1-4 (No.RA018<Rev.002>)
*25 and 30 kHz are not included in the models sold in the USA or US territories.
Analog measurements made per TIA 603 and specifications shown are typical.
P25 Digital measurements made per TIA 102CAAA and specifications shown are typical.
JVC KENWOOD Corporation reserves the right to change specifications without prior notice or obligation.
FM Hum & Noise Analog @ 25 kHz 45dB
Analog @ 12.5 kHz 40dB
Audio Distortion Less than 2%
Modulation 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D, 8K10F1W,
8K30F1E, 8K30F1D, 8K30F7W, 4K00F1E,4K00F1D,
4K00F7W, 4K00F2D

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
