Kenwood NX-5200 Service Manual

(No.RA018<Rev.002>)1-77
7.
Maxi-
mum
Devia-
tion
*2
[Analog
Wide 5k]
1) Adj item:
[Aw ADEV]
Adjust:[****]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Adjust:[****]
PTT : ON
Press [ ] key to
store the adjust-
ment value.
1) Adj item:
[Maxmum Devia-
tion (Analog Wide
5k)]
Deviation meter
LPF: 15kHz
HPF: OFF
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Press [Transmit]
button.
Press [Apply All]
button to store the
adjustment value.
Devia-
tion
meter
Oscil-
lo-
scope
Panel ANT Panel [Pan-
el tun-
ing
mode]
[],
[]
[PC
test
mode]
[←],
[→]
Write fixed value “503”
for each adjustment
point. Transmit at each
adjustment point and
check that the deviation
is between 4150Hz and
4250Hz.
Deviation meter
LPF: 15kHz
HPF: OFF
[Panel tuning mode]
PTT: ON
[PC test mode]
PTT: Press [Transmit]
button
4150~4250Hz
[PC test
mode]
Press [Apply
All] button to
store the
adjustment
value after all
adjustment
points have
been adjusted.
[Analog
Wide 4k]
*2
1) Adj item:
[As ADEV]
Adjust:[****]
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]
→
[High3]
Adjust:[****]
PTT : ON
Press [ ] key to
store the adjust-
ment value.
1) Adj item:
[Maxmum Devia-
tion (Analog Wide
4k)]
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Press [Transmit]
button.
Press [Apply All]
button to store the
adjustment value.
Devia-
tion
meter
Oscil-
lo-
scope
Panel ANT Panel [Pan-
el tun-
ing
mode]
[],
[]
[PC
test
mode]
[←],
[→]
Write fixed value “503”
for each adjustment
point. Transmit at each
adjustment point and
check that the deviation
is between 3310Hz and
3410Hz.
Deviation meter
LPF: 15kHz
HPF: OFF
[Panel tuning mode]
PTT: ON
[PC test mode]
PTT: Press [Transmit]
button
3310~3410Hz
[PC test
mode]
Press [Apply
All] button to
store the
adjustment
value after all
adjustment
points have
been adjusted.
[Analog
Narrow]
*2
1) Adj item:
[An ADEV]
Adjust:[****]
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Adjust:[****]
PTT : ON
Press [ ] key to
store the adjust-
ment value.
1) Adj item:
[Maxmum Devia-
tion (Analog Nar-
row)]
2) Adj item:
[Low1]→
[Low3]→
[Center2]→
[High1]→
[High3]
Press [Transmit]
button.
Press [Apply All]
button to store the
adjustment value.
Devia-
tion
meter
Oscil-
lo-
scope
Panel ANT Panel [Pan-
el tun-
ing
mode]
[],
[]
[PC
test
mode]
[←],
[→]
Write fixed value “503”
for each adjustment
point. Transmit at each
adjustment point and
check that the deviation
is between 2050Hz and
2150Hz.
Deviation meter
LPF: 15kHz
HPF: OFF
[Panel tuning mode]
PTT: ON
[PC test mode]
PTT: Press [Transmit]
button
2050~2150Hz
[PC test
mode]
Press [Apply
All] button to
store the
adjustment
value after all
adjustment
points have
been adjusted.
*2 : Refer to the “4.19.1 Necessary Deviation adjustment item for each signaling and mode” table.
Regarding Maximum Deviation (Analog), it is common with the adjustment of all analog signalings.
Item Condition Measurement Adjustment Specifica-
tions
/Remarks
Panel tuning
mode
PC test mode Test-
equip-
ment
Unit Ter-
minal
Unit Parts Method
