Kenwood TH-D74A/E - microSD Card Usage; Recording Data

6 Settings & Controls
57
USB Mass Storage Class 6.11.3
This feature is supported on digital cameras and the TH-D74A/E, it allows access to the
different settings as well as the microSD memory card on the TH-D74A/E from a PC using
the MCP-D74 Memory Control Program by connecting the PC to the USB port.
There is no need to remove the memory card from this transceiver. To connect the
TH-D74A/E with a PC, it is necessary to install a virtual COM port driver on the PC in
advance.
To make use of this feature, change the USB device selection option
in
Menu No. 980 to "Mass Storage".
6.12 microSD Card Usage
Recording Data 6.12.1
The TH-D74A/E is compatible with the microSD and microSDHC standards. It supports
microSDHC cards with a capacity of up 32 GB.
The following types of information can be recorded to a microSD card.
Type
Description
Maximum No. of
Files
File Format
Transmitted/Received
Audio Recording
Records the communication of
data transmitted and received.
255
wav
16 kHz/ 16
-
bit/ monaural
GPS Tracking Log
Records the GPS tracking data.
255
nme
QSO Log
Records the update history.
4000
(
*1
)
tsv (tab-delimited text)
Repeater List
D-STAR repeater list
---
tsv (tab-delimited text)
Callsign List
Callsign list for D-STAR
---
tsv (tab-delimited text)
Captured Image
Screenshot image
---
bmp
240 x 180/ 24-bit
Transceiver
Configuration
Information such as the
configuration of the transceiver
features, as well as memory
channels and voice messages.
---
d74 (binary format)
*1
：
Firmware V1.05 and later versions (255 files for V1.04 and earlier versions)
