ES749 Flow Computer
33
Select the type of uid appropriate for your application.
Selection:
SATURATED STEAM, SUPERHEATED STEAM
Display: SATURATED STEAM
FLUID TYPE
Select the owmeter type used in your application.
Selection:
LINEAR, SQR LAW, SQR LAW-LIN., LINEAR 16 PT, SQR
LAW 16 PT, SQR LAW-LIN. 16 PT, LINEAR UVC, GILFLO,
GILFLO 16 PT, BYPASS, ILVA16PT, MASS FLOW
Display: LINEAR
FLOWMETER TYPE
Select the appropriate input signal.
Selection:
4-20 mA, 0-20 mA, 0-5 Vdc, 1-5 Vdc, 0-10 Vdc, DIGITAL:
10 mV LEVEL, DIGITAL: 100 mV LEVEL, DIGITAL: 2.5 V
LEVEL, 4-20mA STACKED, 0-20mA STACKED, 4-20mA
LINEAR MANIFOLD, 0-20mA LINEAR MANIFOLD
Display: DIGITAL 2.5 V LEVEL
INPUT SIGNAL
Enter the K-Factor for the owmeter.
Input:
Number with oating decimal point:
0.0001...999999
Display: 123.67 P/ft3
K-FACTOR
Select the appropriate pressure input signal.
Selection:
MANUAL PRESSURE, 4-20 PRESSURE (ABS.), 0-
20 PRESSURE (ABS.), 4-20 PRESSURE (G), 0-20
PRESSURE (G)
Display: 4-20 PRESSURE (ABS.)
INPUT SIGNAL
EZ SETUP
Fluid Type
FLOWMETER TYPE
INPUT SIGNAL
K-FACTOR
INPUT SIGNAL
(PRESSURE)
6.2
EZ
SETUP
(Continued)
