KEP ES749 - Network Card

ES749 Flow Computer
85
The ow computer can be connected via RS-485 interface to a
personal computer and communicate via Modbus RTU protocol.
Selection:
MODBUS RTU
Display: MODBUS RTU
PROTOCOL
Enter the unique unit I.D. tag number for the ow computer if a
number of ow computers are connected to the same interface.
Selection:
3 digit number: 1...247
Display: 1
DEVICE ID
Enter the baud rate for serial communication between the ow
computer and a personal computer.
Selection:
19200, 9600, 4800, 2400, 1200, 600, 300
Display: 9600
BAUD RATE
Select the desired parity. The setting selected here must agree with
the parity setting for the computer.
Selection:
NONE, ODD, EVEN
Display: NONE
PARITY
PROTOCOL
DEVICE ID
BAUD RATE
PARITY
NETWORK CARD
6.14
NETWORK
CARD
