ES749 Flow Computer
65
Enter the Flowmeter Location
Selection:
Hot, Cold:
Display: COLD
FLOWMETER LOCATION
Enter the Bypass Calibration Factor.
Input:
Max. 6 digit number: 0.000001...999999
Display: 1.000000
BYPASS CAL. FACTOR
Enter the Bypass EAm Factor.
Input:
Max. 6 digit number: 0.000001...999999
Display: 1.000000
BYPASS EAM FACTOR
Enter the Bypass DC Factor.
Input:
Max. 6 digit number: 0.1...10.0
Display: 1.000000
BYPASS DC FACTOR
Enter the Bypass Ym Factor.
Input:
Max. 6 digit number: 0.001...1.0
Display: 1.000000
BYPASS YM FACTOR
6.8
FLOW INPUT
(Continued)
FLOW INPUT
VIEW INPUT SIGNAL
This feature is used to see the present value of the ow input signal.
The type of electrical signal is determined by the owmeter input
signal type selection.
Display: 150 Hz
VIEW INPUT SIGNAL
BYPASS CAL.
FACTOR
BYPASS EAm
FACTOR
BYPASS DC
FACTOR
BYPASS Ym
FACTOR
FLOWMETER
LOCATION
VIEW HIGH RANGE
SIGNAL
This feature is used to see the present value of the high range
ow input signal. The type of electrical signal is determined by the
owmeter input signal type selection.
Display: 4 mA
VIEW HIGH RANGE SIGNAL
To Next Page
