ES749 Flow Computer
67
6.9
OTHER
INPUT
(Continued)
OTHER INPUT
Set the low scale value for the analog current input signal (value for
0 or 4 mA input current). The value entered here must be identical to
the value set in the pressure, temperature or density transmitter.
Input:
Number with xed decimal point: -9999.99...+9999.99
Display: 32.00 of
LOW SCALE VALUE
Set the full scale value for the analog current input signal (value for
20 mA input current). The value entered here must be identical to the
value set in the pressure, temperature or density transmitter.
Input:
Number with xed decimal point: -9999.99...+9999.99
Display: 752.00 of
FULL SCALE VALUE
A xed value can be dened for the assigned variable (pressure,
temperature, density). The ow computer will use this value in the
following cases:
• In case of error (i.e. defective sensors). The ow computer
will continue to operate using the value entered here.
• if "MANUAL TEMPERATURE", "MANUAL PRESSURE" or
"MANUAL DENSITY" was selected for "INPUT SIGNAL".
Input:
Number with xed decimal point: -9999.99...+9999.99
Display: 70.00 of
DEFAULT VALUE
Dene the STP reference conditions (standard temperature and
pressure) for the variable assigned to the input. Presently, standard
conditions are dened differently depending on the country and
application.
Input:
Number with xed decimal point:
-9999.99...+9999.99
Display: 60.00 of
STP REFERENCE
LOW SCALE VALUE
FULL SCALE VALUE
DEFAULT VALUE
STP REFERENCE
