ES749 Flow Computer
91
This feature allows the units setup parameters to be printed to a
connected printer.
Display: NO
PRINT SYSTEM SETUP
This feature starts the self-test of the ow computer. A test is
internally conducted on the EEPROM, A/D Converter, Time/Date
clock, Display and several other hardware circuits.
Display: RUN? NO
SELF CHECK
The Service Test requires a special calibration apparatus that
connects to the rear terminals of the unit. This is used to determine
whether the ow computer or the eld wiring is faulty. The calibration
apparatus may be purchased from your local distributor.
Display: RUN? NO
SERVICE TEST
PRINT SYSTEM SETUP
SELF CHECK
SERVICE TEST
(Not available with 3
Relay option)
NOTE:
This will only appear if
editing is enabled with
the Service Code.
SERVICE & ANALYSIS
6.15
SERVICE &
ANALYSIS
(Continued)
To Next Page
