CFS/CCS-BA-d-1624 82
17.6 I/O-Funktion
RS-232
Abb.: 9 pin d-Subminiaturbuchse
RS232
Pin 2
RXD
Pin 3
TXD
Pin 4
VCC
5V
Pin 5
GND
Schaltpunkt
Pin 1
VB
Pin 5
GND
Pin 6
OK
Pin 7 LOW
Pin 8
HI
Pin 9
BEEP
Schaltungsbeipiel mit Ampel CFS-A03
U
OH
High
-Level Output Voltage 2,4 V
U
OL
Low
-Level Output Voltage
0,4 V
J1
J2
OUT4
OUT3
OUT2
OUT1
COM
GND
IN4
IN3
IN2
IN1
VB
COM
green
red
yellow
beep
AC power
220VA
Ampel
