KERN PLJ Series User Manual

ALJ/ALS/PLJ/PLS-BA-e-1741 11
KERN PLJ 300-3FM PLJ 720-3AM
Weighing range (max) 320 g 720 g
Readability (d) 0.001 g 0.001 g
Reproducibility 0.001 g 0.001 g
Linearity ± 0.003 g ± 0.002 g
Verification value (e) 10 mg 10 mg
Verification class II II
Minimum load (Min) 20 mg 20 mg
Stabilization time (typical) 3 sec. 2 sec.
Minimum unit weight at
piece counting
> 5 mg > 50 mg
Warm-up time 4 hours
Adjustment weight internal
Reference quantities at
piece counting
10, 25, 50, 100, freely selectable
Weighing Units ct, g
Electric Supply 220V – 240 V AC, 50 Hz
Operating temperature + 5° C …. + 35° C
Humidity of air max. 80 % (not condensing)
Underfloor weighing Clevis type eyelet, standard
Housing (B x D x H) mm 210 x 340 x 100
Windshield mm
inside Ø 150, 60 high
outside Ø 160, 70 high
yes
Weighing plate
(stainless steel)
Ø 11 cm Ø 11 cm
Weight kg (net) 4 kg 4.5 kg
Interface RS 232C
