Back and bottom side of the balance
1. Weighing plate
2. RS232C interface
3. Foot screws
4. Mains adapter
connection
5. Housing screws
(in models with four feet
first screw out the two
rear feet)
6. Underfloor weighing
device
2
3
1
4
5
6
5
