11 Data transfer to peripheral devices
For data transfers to peripheral devices, the balance is equipped with an RS232/V24-
interface.
Before the data transfer, the RS232 interface must be synchronised with the one in the
peripheral device in the balance's configuration menu (see Chapter 8.8 “Interface
functions”).
• Handshake
The handshake is set to “NO” (none) from the factory. It can be set to software
handshake XON/XOFF, or to hardware handshake.
• Baud rate
Possible baud rates: 300, 600, 1,200, 2,400, 4,800, 9,600 baud.
• Parity
Possible parity: 7 even 1 stop, 7 odd 1 stop, 7 No 2 stop or 8 No 1 stop.
1 2 34 5 67 8SP
± 12 V SB 1 2 3 4 5 6 7 8 9
7 even 1 SB 1
st
DA 2
nd
DA
3
rd
DA 4
th
DA 5
th
DA 6
th
DA 7
th
DA PB SP
7 odd 1 SB 1
st
DA 2
nd
DA
3
rd
DA 4
th
DA 5
th
DA 6
th
DA 7
th
DA PB SP
7 no 2 SB 1
st
DA 2
nd
DA
3
rd
DA 4
th
DA 5
th
DA 6
th
DA 7
th
DA 1
st
SP 2
nd
SP
8 no 1 SB 1
st
DA 2
nd
DA
3
rd
DA 4
th
DA 5
th
DA 6
th
DA 7
th
DA 8
th
DA SP
SB: Start Bit PB: Parity Bit
DA: Data Bit SP: Stop Bit
