Warnings:
◆Use the display with caution. Don’t attempt to release or link the connector when battery is
on.
◆Try to avoid hitting the display.
◆Don’t modify system parameters to avoid parameter disorder.
◆Make the display repaired when error code appears.
*This manual instruction is a universal version for DISPLAY KD986. Some versions
of this display may be different from specification to specification as to the software.
Please always refer to an actual version.
Attached list 1：Error code definition
Attached list 2：Assist level ratio defaults
Level
PAS
Level mode
1
2
3
4
5
6
7
8
9
0-3/1-3
50%
74%
92%
—
—
—
—
—
—
0-5/ 1-5
50%
61%
73%
85%
96%
—
—
—
—
0-7/ 1-7
40%
50%
60%
70%
80%
90%
96%
—
—
0-9/ 1-9
25%
34%
43%
52%
61%
70%
79%
88%
96%
Error Code
Definition
21
Current Abnormality
22
Throttle Abnormality
23
Motor Phase Abnormality
24
Motor Hall Signal Abnormality
25
Brake Abnormality
30
Communication Abnormality
