Keyscan Inc. A Member of the Kaba Group – CA8WL-AL Rev. B Installation Guide (07.15)
11
Figure 2 - Remove the Right Cover
CARD
BITS
10s 1s
SYSTEM
STATUS
COMMUNICATION
STATUS
TD 1
RD 1
TD 2
RD 2
SYSTEM
INPUTS/
RS-485
(TB7)
SERVER
RS-232 (TB5)
ETHERNET
Left Cover - Do not remove.
SYSTEM STATUS LEGEND
GREEN – NORMAL
AMBER - SERVER COMMS FAULT
RED SOLID - RESET/FAULT
RED FLASHING - CLEARING MEMORY
Removable Right Cover
Knurled Screw Head
Knurled Screw Head
KI-00524E-12-14
KEYSCAN
CA8WL
