Keyscan CA8WL-AL - Figure 4 - CA8 WL-AL Mount - Side View

Keyscan Inc. A Member of the Kaba Group – CA8WL-AL Rev. B Installation Guide (07.15)
13
Figure 4 - CA8WL-AL Mount - Side View
Side View
Mounting Surface
CA8WL-AL Enclosure
Keyway
Cutout
Keyway
Cutout
1/32"
Mounting Surface
CA8WL-AL Enclosure
Keyway
Cutout
Keyway
Cutout
1
Line up bottom part
of keyway cutouts
with screw heads
and place enclosure
against mounting
surface.
2
Slide enclosure
down until the 3
screws are seated
at the top of the
keyway cutouts.
KI-00528E-12-14
