Keyscan Inc. A Member of the Kaba Group – CA8WL-AL Rev. B Installation Guide (07.15)
38
configured network that is exposed publicly and a LAN that is closed. Refer to the network configuration that
best approximates your network application.
Important
You may require the assistance of a qualified network administrator. Without correct host/remote network
settings and connectivity, you will be unable to establish communication.
Table 6 - Reverse Network IP Address Settings
Network Configuration – Internet/Intranet/WAN – Host Router or End Point with External IP
Address
Example
Settings
Host Location
Remote Location
See Figure 18
IP Address
Port #
Gateway
Encryption key
Router with port forward
or router table to
Server/workstation with
Keyscan reverse network
encrypted communication
Same encryption key/bit
setting as remote location
ACU
Programmed with host router or
end point external IP address
Port # of host router/end point
ACU Ethernet
Module
Programmed with static IP address
or if using DHCP server dynamic IP
Gateway (if static IP above)
Port # of host router/end point
Same encryption key/bit setting as
host location
Network Configuration – LAN – Closed Network with No Public Exposure
See Figure 19
IP Address
Port #
Encryption key
Server/workstation with
Keyscan reverse network
encrypted communication
Same encryption key/bit
setting as remote location
ACU
Programmed with IP address of
host Server/workstation with
Keyscan reverse network
encrypted communication
Port # of Host Server/workstation
ACU Ethernet
Module
Programmed with static IP address
or if using DHCP server dynamic IP
Port # of Host Server/workstation
Same encryption key/bit setting as
host location
