CIM-LINK Specifications
Operating Voltage
12VDC
Current Draw
CIM-LINK 150 mA + NETCOM2P 140 mA = 290 mA
Dimensions
4 5/8” x 3” (11.7 cm x 7.6 cm)
Operating Environment
Suitable for industrial and commercial applications.
Operating temperatures: 5
0
C to 60
0
C (41
0
F to 140
0
F)
Cables
CAN Bus 2: CAT5, 1 twisted pair, maximum overall cable distance - 3280 ft (1000 m)
CAN Bus
CAN Bus 2: ACU to ACU communication for global functions
Ribbon Cable
CIM—LINK with single ACU communication loop—ribbon cable connects from HDR1 on CIM-
LINK to H2 header on control board. In this configuration, the CIM—LINK/NETCOMP is
powered from the control board.
Topology
Linear – does not support star or ring topologies
Inter-building Connectivity
Yes
NETCOM2P Specifications
Dimensions
1 9/16 " x 1 15/16 " (4.0 cm x 5.1 cm)
Operating Environment
5º C – 70º C (41º F – 158º F)
Network Interface
RJ45 - 10/100 Base-T Ethernet
LAN/WAN (TCP/IP protocol—port 3001)
Compatibility
Ethernet Version 2.0/IEEE802.3
Power Requirements
Powered through CIM-LINK—see current draw above
Agency Approvals—Ethernet Socket
Complies with Class B limits of EN 55022: 1998 Direct & Indirect ESD.
Complies with EN55024:1998
