8163A/B, 8164A/B & 8166A/B Mainframes Programming Guide 213
Measurement Operations & Settings 4
command: :TRIGger[n][:CHANnel[m]]:OUTPut
syntax: :TRIGger[n][:CHANnel[m]]:OUTPut
description: Specifies when an output trigger is generated and arms the module.
parameters: DISabled:
AVGover:
MEASure:
MODulation:
STFinished:
SWFinished:
SWSTarted:
Never.
When averaging time period finishes.
When averaging time period begins.
For every leading edge of a digitally-modulated (TTL) signal
When a sweep step finishes.
When sweep cycle finishes.
When a sweep cycle starts.
response: none
example: trig1:outp dis
affects: All tunable laser modules (except 81950A), series power meters, and return loss modules.
dual sensors: Can only be sent to master channel, slave channel is also affected.
In continuous mode, wav:swe:step:[widt] is used for triggering, see
[:SOURce[n]][:CHANnel[m]]:WAVelength:SWEep:STEP:[WIDTh] on page 179.
command: :TRIGger[n][:CHANnel[m]]:OUTPut?
syntax: :TRIGger[n][:CHANnel[m]]:OUTPut?
description: Returns the condition that causes an output trigger.
parameters: none
response: DISabled:
AVGover:
MEASure:
MODulation:
STFinished:
SWFinished:
SWSTarted:
Never.
When averaging time period finishes.
When averaging time period begins.
For every leading edge of a digitally-modulated (TTL) signal
When a sweep step finishes.
When sweep cycle finishes.
When a sweep cycle starts.
example: trig1:outp? -> dis<END>
affects: All tunable laser modules (except 81950A), power meters, and return loss modules.
dual sensors: Can only be sent to master channel, slave channel parameters are identical.
