Performance Test
Standing Wave Ratio (SWR) and Reflection Coefficient (Rho)
performance test
This section does not establish preset SWR test procedures since there are several
test methods and different equipment available for testing the SWR or reflection
coefficient. Therefore, the actual accuracy of the test equipment must be
accounted for when measuring against instrument specifications to determine a
pass or fail condition. The test system used must not exceed the system Rho
uncertainties shown in the following tables when testing the Keysight E-Series
E9300 power sensors.
Table 4-1 Power sensor SWR and reflection coefficient for the E9300A
Frequency
System Rho
uncertainty
Actual measurement Maximum Rho
10 MHz to 30 MHz ±0.010 0.070
30 MHz to 2 GHz ±0.010 0.061
2 GHz to 14 GHz ±0.010 0.087
14 GHz to 16 GHz ±0.010 0.099
16 GHz to 18 GHz ±0.010 0.115
Table 4-2 Power sensor SWR and reflection coefficient for the E9301A
Frequency
System Rho
uncertainty
Actual measurement Maximum Rho
10 MHz to 30 MHz ±0.010 0.070
30 MHz to 2 GHz ±0.010 0.061
2 GHz to 6 GHz ±0.010 0.087
