4Service
48 Keysight E-Series E9300 Operating and Service Guide
CAUTION
DC voltages in excess of the maximum value (5 Vdc) can damage the
sensing diode.
Table 4-3 Power sensor SWR and reflection coefficient for the E9304A
Frequency
System Rho
uncertainty
Actual measurement Maximum Rho
9 kHz to 2 GHz ±0.010 0.061
2 GHz to 6 GHz ±0.010 0.087
Table 4-4 Power sensor SWR and reflection coefficient for the E9300A
Frequency
System Rho
uncertainty
Actual measurement Maximum Rho
10 MHz to 8 GHz ±0.010 0.057
8 GHz to 12.4GHz ±0.010 0.078
12.4 GHz to 18 GHz ±0.010 0.107
Table 4-5 Power sensor SWR and reflection coefficient for the E9301B
Frequency
System Rho
uncertainty
Actual measurement Maximum Rho
10 MHz to 6 GHz ±0.010 0.057
Table 4-6 Power sensor SWR and reflection coefficient for the E9300H
Frequency
System Rho
uncertainty
Actual measurement Maximum Rho
10 MHz to 8 GHz ±0.010 0.070
8 GHz to 12.4GHz ±0.010 0.111
12.4 GHz to 18 GHz ±0.010 0.123
