Recommended Test Equipment
Table 8-4 describes the test equipment recommended for the performance
verification and adjustment procedures. If the exact equipment is not available,
use the accuracy requirements shown to select substitute calibration standards. If
you use equipment other than the recommended equipment shown in Table 8-4,
you must recalculate the measurement uncertainties for the actual equipment
used.
Table 8-4 Recommended test equipment
Equipment Requirement Recommended model Test function
GPIB controller Full GPIB or RS-232 capabilities Keysight 82341C interface
card or equivalent
Programming and readback
accuracy
Oscilloscope 100MHz with 20 MHz bandwidth Keysight 54602B Display transient response and
ripple and noise waveform
Rms voltmeter 20Hz to 20 MHz - Measure rms ripple and noise
Cable (BNC-to-BNC) 50 Ω, 9 inch (23cm) Keysight 10502A or 10503A if
the 10502A is not available
Measure rms ripple and noise
(CV PARD, CC PARD)
BNC (female) bulkhead
receptacle
– Isolated ground
– Nominal impedance: 50 Ω
Pomona model 5148 Measure rms ripple and noise
(CV PARD, CC PARD)
Split ferrites For use with round cables Steward Co. 28A2029-0A0 Noise coupling reduction
Digital voltmeter – Resolution: 0.1 mV
– Accuracy: 0.01%
Keysight 34401A Measure DC voltages
Electronic load – Voltage range: 240 Vdc
– Current range: 10 Adc
– Open and short switches
– Transient on/off
Keysight 60503B Measure load and line
regulations and transient
response time
