Getting Started 1
Keysight E364xA User’s and Service Guide 29
Figure 1-1 Rear output terminals
1 Float voltage ±60 Vdc Max to (shorting conductors without insulation).
2 Float voltage ±240 Vdc Max to (insulated shorting conductors).
Floating the power supply output at more than ±60 Vdc from the chassis
presents an electric shock hazard to the user.
Do not float the outputs at more than ±60 Vdc when uninsulated sense wires
are used to connect the (+) output to the (+) sense and the (–) output to the
(–) sense terminals on the back of the unit.
