Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 15
Maximum voltage at oscilloscope external trigger input / 181
12 Acquisition Control
Running, Stopping, and Making Single Acquisitions (Run
Control) / 183
Overview of Sampling / 184
Sampling Theory / 185
Aliasing / 185
Oscilloscope Bandwidth and Sample Rate / 185
Oscilloscope Rise Time / 187
Oscilloscope Bandwidth Required / 188
Memory Depth and Sample Rate / 189
Selecting the Acquisition Mode / 189
Normal Acquisition Mode / 190
Peak Detect Acquisition Mode / 190
Averaging Acquisition Mode / 193
High Resolution Acquisition Mode / 195
Acquiring to Segmented Memory / 195
Navigating Segments / 197
Measurements, Statistics, and Infinite Persistence with
Segmented Memory / 197
Segmented Memory Re-Arm Time / 198
Saving Data from Segmented Memory / 198
13 Cursors
To make cursor measurements / 202
Cursor Examples / 205
14 Measurements
To make automatic measurements / 212
