114 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Service and Utility Menus
Utility Service Menu
Service
The service menu contains functions that are needed to complete assembly
replacements.
Remove Assembly
The idea behind the Remove Assembly menu, and all the “Prepare” functions
within it, was to do any data transfer needed before removing an assembly that
needed to be replaced. However, nothing has ever been implemented for these
functions, so there currently is no use for this menu.
There are four types of instrument information that one should be concerned
about when an assembly is being removed and replaced with a replacement
assembly. They are:
— The instrument model number
— The instrument serial number
— The instrument licenses
— The instrument calibration data
For information on how and where all of these are saved in the instrument, see
Chapter 3, “Instrument Information and Calibration Data”.
For information on what needs to be done to ensure that none of these are lost
when an assembly is replaced, see Chapter 16, “Pre and Post-Repair
Procedures”.
