232 Keysight CXG, EXG, and MXG X-Series Signal Generators Service Guide
Micro-Deck Assembly
A8 BNC Bypass Board Overview
A8 BNC Bypass Board Overview
The A8 BNC Bypass board isolation circuit is a filter that minimizes interference
caused when external equipment is connected to the rear panel external ALC
IN connector. The circuit isolates DC voltage and high frequency signal
components that might be present between different grounding paths.
