426 Keysight EXG and MXG X-Series Signal Generators User’s Guide

Using the N5102A Digital Signal Interface Module for N5172B/82B with Option 003/004 and

653/655/656/657

Clock Timing

1 Sample Period

4 Clocks Per Sample

4 Clocks

Sample rate decreases by a factor of four

I sample

Q sample

Clock

4 bits per word

1 Sample Period

2 Clocks Per Sample

2 Clocks

I sample

Q sample

Sample rate decreases by a factor of two

Clock

4 bits per word
