3 Specifications and Characteristics
38 U2000 Series Operating and Service Guide
Specifications
Frequency and Power Ranges
Connector Type
Model Frequency Range Power Range
U2000A 10 MHz to 18.0 GHz
–60 dBm to +20 dBm
U2001A 10 MHz to 6.0 GHz
U2002A 50 MHz to 24 GHz
U2004A 9 kHz to 6.0 GHz
U2000H 10 MHz to 18 GHz
–50 dBm to +30 dBmU2001H 10 MHz to 6 GHz
U2002H 50 MHz to 24 GHz
U2000B 10 MHz to 18 GHz
–30 dBm to +44 dBm
U2001B 10 MHz to 6 GHz
Model Connector Type Impedance
U2000/1/4A N-Type (m) 50 Ω
U2002A 3.5 mm (m) 50 Ω
U2000/1H N-Type (m) 50 Ω
U2002H 3.5 mm (m) 50 Ω
U2000/1B N-Type (m) 50 Ω
